Product Overview

This dual-port AC power RF filter connector is designed for AC power feedthrough in shielded test environments.

It integrates two AC power channels within a fully shielded aluminum alloy enclosure. The unit enables AC power to pass through the wall of a shielded box or RF/EMC test chamber while suppressing RF leakage through the power feedthrough path.

The built-in filtering structure helps reduce conducted and coupled RF interference along power lines, supporting the overall shielding effectiveness of the test enclosure. It is suitable for RF testing of wireless products and EMC test applications.

Specifications

Typical Application Scenarios

• AC power feedthrough and RF isolation for shielded boxes and RF/EMC test chambers

• Power supply systems for automated RF testing of wireless communication modules

• EMC testing of Wi-Fi, Bluetooth, and IoT products

• Parallel AC power distribution for multiple DUTs in shielded test environments

• RF-interference suppression for power connections in RF test laboratories

Selection Tips

This product is part of the AC/DC power RF filter connector series.

Single-port and multi-port AC/DC power modules can be customized according to application requirements. Power interfaces can also be combined with RJ45, USB, DB-series, and other data interfaces to form integrated combination RF filter connectors.

Customized interface configurations, port quantities, electrical ratings, and mechanical structures are available based on specific test system requirements.
