Product Overview

The LK-6402-MA Shielding Box is an RF shielding enclosure designed for PCB-level and wireless module development and mass production testing, focusing on board-level wireless RF performance verification. The enclosure supports both manual and pneumatic opening/closing modes, with multiple built-in standard signal interfaces and integrated SMA RF channels, USB interfaces, and DB-series data interfaces. Its excellent RF shielding performance effectively isolates external electromagnetic interference, providing a stable RF testing environment inside the enclosure. It is widely used for RF parameter calibration and functional testing of Wi-Fi, Bluetooth, IoT wireless modules, and PCB motherboards. The LK-6402-MA is suitable for laboratory R&D verification and automated production line batch testing applications.

Technical Specifications

Application Scenarios

✅ Wi-Fi, Bluetooth BLE, and IoT wireless module board-level RF automated testing

✅ Intelligent hardware PCB motherboard, wireless carrier board receiver sensitivity, transmission power performance testing

✅ Multi antenna module MIMO performance testing, antenna matching debugging, and RF function calibration

✅ Final testing of consumer electronics control board and wireless network card module production line

✅ RF performance assessment and comparative testing in R&D laboratory

✅ Automated testing assembly line, multi-channel parallel board-level RF testing station

Selection Tips

The LK-6402-MA is a specialized multi-interface shielding box designed for board-level RF testing, featuring multiple SMA RF channels and supporting multi-antenna module PCB testing. Liankang also provides shielding boxes with different cavity sizes and interface configurations to meet various testing requirements. For applications requiring audio testing and automatic focusing functions, the LK-7900 integrated RF and audio shielding box can be selected. For additional interfaces such as Type-C, RJ45, and audio connections, corresponding filtering feedthrough connectors can be customized according to testing requirements.
